Point d’accès Altai SUPER WIFI CPE (C1N)
1 201.20 DH HT
Max. LOS Access jusqu’à 1 km en extérieur (5 GHz). Max. Data Rate de 300 Mbps pour une couverture étendue. Max. LOS CPE 4 km vers A8-Ein(ac), 3 km vers A3-Ei.
Description
| **Max. Access Line of Sight (LOS) | ** |
| – **Maximum Access (5 GHz) | ** 1 km |
| – **Maximum Customer Premises Equipment (CPE) | ** |
– 4 km to A8-Ein(ac)
– 3 km to A3-Ei
| – **Maximum Bridge LOS | ** 13 km |
| **Data Rate | ** |
| – Maximum Data Rate | 300 Mbps |
| **Coverage | ** |
– Super Long Range Coverage
| **Wireless Interface | ** |
| – **Radio Standard | ** 802.11a/n (2×2) |
| – **Operating Mode | ** AP / CPE / Bridge / Repeater |
| – **Operating Frequency | ** |
– 5.150 – 5.350 GHz
– 5.470 – 5.725 GHz
– 5.725 – 5.850 GHz
| – **Transmit Power | ** |
| – Maximum | 29 dBm |
| – Per Chain | 26 dBm |
| **Receiver Sensitivity | ** |
| – **802.11a | ** |
| – 54 Mbps | -83 dBm |
| – 6 Mbps | -96 dBm |
| – **802.11n | ** |
| – HT20 | -95 dBm |
| – HT40 | -91 dBm |
| **SSID and Features | ** |
| – Maximum SSID | 16 |
| – Supported Features |
– 802.11h, 802.11k, 802.11r, 802.11v, 802.11w
– Hotspot 2.0
– Altai AirFi™ Throughput Optimization
– Band Steering
– WMM (802.11e)
| **Antenna | ** |
| – **Built-in Antenna | ** 5 GHz Antenna, 14 dBi Dual Slant ±45° Sector |
| – **Horizontal Beamwidth | ** 35 – 45° (-3 dB) |
| – **Vertical Beamwidth | ** 15 – 20° (-3 dB) |
| – **Front-to-back Ratio | ** -20 dB (Max.) |
| **Networking Capabilities | ** |
| – Modes | Switch (Bridge) and Gateway Mode |
– Supports IPv4/IPv6 Dual-stack
| – Features | NAT, DHCP Client/Server, PPPoE Client, VPN (IPsec), VLAN, Bandwidth Control Per VAP/Client, Multicast Rate Filter/IGMP Snooping |
| **Security Features | ** |
| – Authentication | Open system, Shared key, WPA/WPA-PSK, WPA2/WPA2-PSK, 802.1x (EAP-PEAP/TLS/TTLS/SIM/AKA) |
| – Encryption | WEP, TKIP, AES |
| – Additional Features | Inter/Intra-client Isolation, MAC-based Access Control (White/Black List), RADIUS, Active Directory, Firewall, WIPS |
| **Management Options | ** |
– Cloud or Server-based Management via AltaiCare
– Controller-based Management through Access Controller
| – Interfaces | Web User Interface, Command Line Interface (SSH), SNMP v1/v2c/v3, Syslog |
| – Additional Management Features | Auto Channel Selection, TX Power Control, Spectral Analysis, KPI Monitoring, Client OS Detection |
| **Physical Specifications | ** |
| – Dimensions | 242 x 80 x 27 mm (excluding mounting) |
| – Weight | 0.4 kg |
| – Mounting Options | Desktop, Pole, Wall, or Window-mounted |
| – Network Interface | 10/100 Mbps Ethernet Port |
| – LED Display | Main Power Status, Ethernet Status, 8-level Signal Strength |
| **Power Supply | ** |
– Configurable Power Supply
| – Power Supply Options | 18V Passive PoE PD or 802.3af PoE PD via Adapter |
| – Power Consumption | 6 W (Typical) / 8 W (Max.) |
| **Environmental Specifications | ** |
| – Operating Temperature | -20 °C to +55 °C |
| – Storage Temperature | -40 °C to +80 °C |
| – Humidity | 5 – 95% (Non-condensing) |
| – Wind Loading | Up to 200 km/h (124 mph) |
| – Weatherproofing | Outdoor UV Stabilized Plastic, IP55 Compliant |
